Trees and Bushes
Trees and Bushes is the trees and bushes of the overworld: the conical trees of Hyrule Field, Kakariko's big tree, and the bushes Link walks through for rupees in Ocarina of Time.
Placement
A tree drops its item when Link rolls into it or hits it. A bush drops its item when Link walks through it. These bushes can't be cut or lifted. For those, use Bush/Grass.
Give a tree a Z rotation other than 0 and it drops a Gold Skulltula instead of an item when hit. The Z rotation and the Drop Table field together pick the Skulltula's token flag, so use a pair no other token in the scene uses.
Type variants (25)
This actor is placed in one of these forms. Pick it from the editor's Type dropdown. The value is what the actor's parameters store. Each picture is fitted to its cell, so compare the stated sizes and not the images.
| Value | Type | |
|---|---|---|
![]() | 0 | Conical Tree (Large)~720 units tall |
![]() | 1 | Conical Tree (Medium)~480 units tall |
![]() | 2 | Conical Tree (Small)~288 units tall |
![]() | 3 | Conical Tree Spawner~480 units tallPlaces up to five more of this plant around it, 500 to 700 units out, and moves itself 141 units to one side. The game removes any of them that has no floor under it. |
![]() | 4 | Conical Tree (Spawned)~480 units tallWhat a spawner creates. Placed by hand it is a single plant that the game removes if there is no floor under it. |
![]() | 5 | Oval Tree (Green)~659 units tall |
![]() | 6 | Oval Tree Spawner (Yellow)~659 units tallPlaces up to five more of this plant around it, 500 to 700 units out, and moves itself 141 units to one side. The game removes any of them that has no floor under it. |
![]() | 7 | Oval Tree (Spawned, Yellow)~659 units tallWhat a spawner creates. Placed by hand it is a single plant that the game removes if there is no floor under it. |
![]() | 8 | Oval Tree Spawner (Green)~659 units tallPlaces up to five more of this plant around it, 500 to 700 units out, and moves itself 141 units to one side. The game removes any of them that has no floor under it. |
![]() | 9 | Oval Tree (Spawned, Green)~659 units tallWhat a spawner creates. Placed by hand it is a single plant that the game removes if there is no floor under it. |
![]() | 10 | Kakariko Tree (Adult)~663 units tall |
![]() | 11 | Bush (Green, Small)~155 units tall |
![]() | 12 | Bush (Green, Large)~233 units tall |
![]() | 13 | Bush Spawner (Green, Small)~155 units tallPlaces up to five more of this plant around it, 500 to 700 units out, and moves itself 141 units to one side. The game removes any of them that has no floor under it. |
![]() | 14 | Bush (Spawned, Green, Small)~155 units tallWhat a spawner creates. Placed by hand it is a single plant that the game removes if there is no floor under it. |
![]() | 15 | Bush Spawner (Green, Large)~233 units tallPlaces up to five more of this plant around it, 500 to 700 units out, and moves itself 141 units to one side. The game removes any of them that has no floor under it. |
![]() | 16 | Bush (Spawned, Green, Large)~233 units tallWhat a spawner creates. Placed by hand it is a single plant that the game removes if there is no floor under it. |
![]() | 17 | Bush (Black, Small)~101 units tall |
![]() | 18 | Bush (Black, Large)~152 units tall |
![]() | 19 | Bush Spawner (Black, Small)~101 units tallPlaces up to five more of this plant around it, 500 to 700 units out, and moves itself 141 units to one side. The game removes any of them that has no floor under it. |
![]() | 20 | Bush (Spawned, Black, Small)~101 units tallWhat a spawner creates. Placed by hand it is a single plant that the game removes if there is no floor under it. |
![]() | 21 | Bush Spawner (Black, Large)~152 units tallPlaces up to five more of this plant around it, 500 to 700 units out, and moves itself 141 units to one side. The game removes any of them that has no floor under it. |
![]() | 22 | Bush (Spawned, Black, Large)~152 units tallWhat a spawner creates. Placed by hand it is a single plant that the game removes if there is no floor under it. |
| No preview yet | 23 | Leaf (Green)One falling leaf. It drifts for about 75 frames and disappears. Trees make these themselves when hit, so there is no reason to place one. |
| No preview yet | 24 | Leaf (Yellow)One falling leaf. It drifts for about 75 frames and disappears. Trees make these themselves when hit, so there is no reason to place one. |
Parameters
Beyond the type above, the parameters hold these fields. The editor shows each as a labelled control.
Shown: 0x0000, the value a newly placed copy starts with.
- Type
bits 0–7: 25 options25 of 256 values used - Drop Table
bits 8–14: 0–127all 128 values usedWhich item table the tree or bush draws from when hit. 0 is a table, not nothing. Values from 100 up drop nothing. - No Drop
bit 15: on / offDrops nothing, whatever the Drop Table says.
Rotation fields
This actor reads these rotation fields as settings, not as a direction. The editor shows each one as a number field.
| Field | Axis | What it does |
|---|---|---|
| Skulltula Group | Z | Any value other than 0 makes a tree drop a Gold Skulltula, and a bush drop nothing. The token group is this number minus 1, repeating every 32. |
Appears in (8)
Hyrule Castle
Hyrule Field
Kakariko Village
Lon Lon Ranch
Market Day
Market Night
Zoras Fountain
Zoras RiverModel
What this actor draws, and where each piece lives in the archive. A mod replaces a piece by writing a file at the same path.
| Display lists | objects/object_wood02/object_wood02_DL_0078D0objects/object_wood02/object_wood02_DL_007968 |
|---|
| Display lists | objects/object_wood02/object_wood02_DL_007CA0objects/object_wood02/object_wood02_DL_007D38 |
|---|
| Display lists | objects/object_wood02/object_wood02_DL_0080D0objects/object_wood02/object_wood02_DL_0081A8 |
|---|
| Display list | objects/object_wood02/object_wood02_DL_000090 |
|---|
| Display list | objects/object_wood02/object_wood02_DL_000340 |
|---|
Objects loaded
objects/object_wood02
