Door

Door is the standard door between two rooms in Ocarina of Time.

← All actors

Placement

Prelude places a door between two rooms, not inside one. Pick both rooms when you place it. The game loads the room on the far side when Link opens the door. A door that leads out of the scene names its own room on both sides. The door's look comes from the scene, and Prelude adds the object the scene needs.

Type variants (8)

This actor is placed in one of these forms. Pick it from the editor's Type dropdown. The value is what the actor's parameters store.

	Value	Type
	0	Room LoadOpens and loads the room on the other side. Types 0, 2 and 7 are the same.
	1	Locked (small key)Needs a small key. Opening it uses one key and sets the switch flag, so it stays open.
	2	Room Load (2)The same as Room Load.
	3	Scene ExitOpens without loading a room. Walking through uses the floor's exit, which is how a door leads to another scene.
	4	AjarSits slightly open. It slams shut when Link comes near and never opens.
	5	CheckableNever opens. Pressing A shows a text box.
	6	EveningWorks as a scene exit from 18:00 to 21:00. At other times it is checkable. Dampé's hut uses this.
	7	Room Load (7)The same as Room Load.

Parameters

Beyond the type above, the parameters hold these fields. The editor shows each as a labelled control.

• Transition Index bits 10–15: 0–63all 64 values usedWhich entry of the scene's door list this actor uses. The entry names the two rooms it sits between and the camera used walking through. Prelude sets it when you pick the rooms, so leave it alone. A value past the end of the list crashes the game.
• Type bits 7–9: 0 Room Load, 1 Locked (small key), 2 Room Load (2), 3 Scene Exit, 4 Ajar, 5 Checkable, 6 Evening, 7 Room Load (7)all 8 values usedWhat the door does.
• Double Door bit 6: on / offMakes a two-leaf door centered on this spot. Each leaf sits 30 units from it, facing the other way. One entry makes both leaves.
• Switch Flag bits 0–5: 0–63. Read when Type is Locked.all 64 values usedSet when the door is unlocked, so it stays open. Keep the flag unique to this door. Two locked doors sharing a flag unlock together. One of the scene's 64 switch flags. Actors that share a number are linked: when one sets it, every actor reading it reacts. Flags 0 to 31 are saved with the game, 32 to 55 reset when you leave the scene, and 56 to 63 reset on every room change. Pick a number nothing else in this scene uses unless you mean to link them. The panel's link list shows who shares it.
• Text bits 0–5: 0–63. Read when Type is Checkable.all 64 values usedThe text this actor shows. Pick a message from the browser, which lists the text of every entry, or add your own. The value stored here is the message id minus this actor's fixed base.

Appears in (34)

Back Alley DayBack Alley HouseBack Alley NightBombchu Bowling AlleyBottom Of The WellDog Lady HouseFire TempleFishing PondForest TempleGravekeepers HutGraveyardHouse Of SkulltulaHyrule CastleIce CavernImpas HouseKakariko Center Guest HouseKakariko VillageLake HyliaLakeside LaboratoryLon Lon BuildingsLon Lon RanchMarket DayMarket Entrance DayMarket Entrance NightMarket Entrance RuinsMarket Guard HouseMarket NightPotion Shop GrannyShadow TempleShooting GalleryStableTreasure Box ShopWater TempleWindmill And Dampes Grave

Model

What this actor draws, and where each piece lives in the archive. A mod replaces a piece by writing a file at the same path. A replaced limb is a part the actor swaps in while it draws. An added limb is a part it draws on top of the skeleton.

Objects loaded

• objects/gameplay_keep shared with 105 other actors
• objects/gameplay_field_keep shared with 10 other actors
• objects/gameplay_dangeon_keep shared with 10 other actors

An edit to a shared object reaches every actor that loads it.

Door actors

Room changing plane · Shutter Door
