Warp Portal

Warp Portal is an item/action actor in Ocarina of Time.

← All actors

Placement

BrokenNo variant is a general-purpose warp: the working blue warps (0/-1) only complete in their hard-coded boss rooms and SOFT-LOCK the player elsewhere (grabbed and floated, never warped); -2 blacks out the scene and seizes Link; 6 despawns outside its exact blue-warp arrival; and 2/4/7/8/9/10 are decorative flashes. Params 3 (the purple crystal) is the safest decoration.

Type variants (12)

This actor is placed in one of these forms. Pick it from the editor's Type dropdown. The value is what the actor's parameters store. Each picture is fitted to its cell, so compare the stated sizes and not the images.

ValueType
Blue Crystal (setpiece)65534Blue Crystal (setpiece)~160 units tall
Dungeon Warp (Adult)65535Dungeon Warp (Adult)~580 units tall
Dungeon Warp (Child)0Dungeon Warp (Child)~460 units tall
Warp On Room Clear1Warp On Room Clear~460 units tall
Sages (cutscene)2Sages (cutscene)~460 units tall
Purple Crystal (setpiece)3Purple Crystal (setpiece)~123 units tall
Yellow (setpiece)4Yellow (setpiece)~460 units tall
Blue — Ruto (setpiece)5Blue — Ruto (setpiece)~460 units tall
Arrival Point6Arrival Point~460 units tall
Orange (setpiece)8Orange (setpiece)~460 units tall
Green (setpiece)9Green (setpiece)~460 units tall
Red (setpiece)10Red (setpiece)~460 units tall
BrokenParams must be one of the defined warp variants (-2, -1, 0-10) — anything else assigns no behavior and crashes on the next frame.

Parameters

Beyond the type above, the parameters hold these fields. The editor shows each as a labelled control.

15141312111098765432100000000000000000Type

Shown: 0x0000, the value a newly placed copy starts with.

Appears in (9)

Chamber Of The SagesChamber Of The SagesDeath Mountain CraterDeath Mountain CraterDeath Mountain TrailDeath Mountain TrailDesert ColossusDesert ColossusGraveyardGraveyardKokiri ForestKokiri ForestLake HyliaLake HyliaSacred Forest MeadowSacred Forest MeadowShooting GalleryShooting Gallery

Model

What this actor draws, and where each piece lives in the archive. A mod replaces a piece by writing a file at the same path.

Blue Crystal (setpiece) · Purple Crystal (setpiece)
Skeletonobjects/object_warp1/gWarpCrystalSkel
Animationobjects/object_warp1/gWarpCrystalAnim
Dungeon Warp (Adult)
Skeletonobjects/object_warp1/gWarpCrystalSkel
Animationobjects/object_warp1/gWarpCrystalAnim
Display listobjects/object_warp1/gWarpPortalDL
Dungeon Warp (Child) · Warp On Room Clear · Sages (cutscene) · Yellow (setpiece) · Blue — Ruto (setpiece) · Arrival Point · Orange (setpiece) · Green (setpiece) · Red (setpiece)
Display listobjects/object_warp1/gWarpPortalDL

Objects loaded
