Collectibles

Collectibles is an actor in Ocarina of Time.

← All actors

Placement

Bits 8-13 are its collectible flag — already set in the save means it despawns at load, and picking it up sets it. The low byte is the item (0x00-0x1A: rupees, hearts, ammo, key, heart piece/container, shields, tunics); 0x1B-0x1D are SoH-internal values.

Item variants (27)

This actor is placed in one of these forms. Pick it from the editor's Item dropdown. The value is what the actor's parameters store. Each picture is fitted to its cell, so compare the stated sizes and not the images.

	Value	Item
	0	Green Rupee~19 units tall
	1	Blue Rupee~19 units tall
	2	Red Rupee~19 units tall
	3	Recovery Heart~17 units tall
	4	Bombs (A)~15 units tall
	5	Arrow~10 units tall
	6	Heart Piece~28 units tall
	7	Heart Container~37 units tall
	8	Arrows (5)~18 units tall
	9	Arrows (10)~18 units tall
	10	Arrows (30)~18 units tall
	11	Bombs (B)~15 units tall
	12	Deku Nuts (5)~15 units tall
	13	Deku Stick~15 units tall
	14	Magic (Large)~23 units tall
	15	Magic (Small)~15 units tall
	16	Deku Seeds (5)~15 units tall
	17	Small Key~15 units tall
No preview yet	18	Flexible
	19	Gold Rupee~58 units tall
	20	Purple Rupee~39 units tall
	21	Deku Shield~5 units tall
	22	Hylian Shield~6 units tall
	23	Zora Tunic~10 units tall
	24	Goron Tunic~10 units tall
	25	Bombs (Special)~15 units tall
No preview yet	26	Bombchus

Parameters

Beyond the item above, the parameters hold these fields. The editor shows each as a labelled control.

• Automatically Collect bit 15: on / off
• Collectible Flag bits 8–13: 0–63all 64 values used
• Item bits 0–7: 27 options27 of 256 values used

Appears in (28)

Bottom Of The WellDeath Mountain CraterDeath Mountain TrailDeku TreeDesert ColossusDodongos CavernFire TempleForest TempleGerudo Training GroundGerudo ValleyGerudos FortressGraveyardGrottosIce CavernImpas HouseInside Ganons CastleKokiri ForestLake HyliaLakeside LaboratoryLon Lon BuildingsLost WoodsSarias HouseShadow TempleSpirit TempleWater TempleWindmill And Dampes GraveZoras FountainZoras River

Model

What this actor draws, and where each piece lives in the archive. A mod replaces a piece by writing a file at the same path.

Objects loaded

• objects/object_gi_heart shared with 2 other actors
• objects/object_gi_shield_1 shared with 2 other actors
• objects/object_gi_shield_2 shared with 3 other actors
• objects/object_gi_clothes shared with 2 other actors
• objects/gameplay_keep shared with 105 other actors

An edit to a shared object reaches every actor that loads it.
