Gameplay_keep items

Gameplay_keep items is an actor in Ocarina of Time.

← All actors

Placement

The low byte picks the piece: 0-4 pushable/static blocks, 5 a cube, 7 grass clump, 8 tree stump, 9/0xA the two SIGNPOSTS (the only types vanilla uses; their text id is the HIGH byte, read as message 0x300 + value), 0xB a boulder fragment. Types past 0xB just draw as the fragment.

Type variants (12)

This actor is placed in one of these forms. Pick it from the editor's Type dropdown. The value is what the actor's parameters store. Each picture is fitted to its cell, so compare the stated sizes and not the images.

	Value	Type
	0	Block (small)~60 units tall
	1	Block (large)~120 units tall
	2	Block (huge)~240 units tall
	3	Block (small, rotated)~18 units tall
	4	Block (large, rotated)~36 units tall
	5	Cube (small)~60 units tall
	6	Hookshot post~100 units tall
	7	Grass clump~32 units tall
	8	Tree stump~23 units tall
	9	Signpost (oblong)~60 units tall
	10	Signpost (arrow)~52 units tall
	11	Boulder fragment~12 units tallThe boulder fragment (0xB, and anything higher) is falling debris with gravity, not a persistent prop.

Parameters

Beyond the type above, the parameters hold these fields. The editor shows each as a labelled control.

• Type bits 0–7: 12 options12 of 256 values used
• Sign text bits 8–15: 0–255. Read when Type = Signpost.all 256 values usedThe text this actor shows. Pick a message from the browser, which lists the text of every entry, or add your own. The value stored here is the message id minus this actor's fixed base.

Appears in (11)

Death Mountain CraterDeath Mountain TrailGerudo ValleyGerudos FortressHaunted WastelandHyrule FieldKakariko VillageKokiri ForestLake HyliaZoras DomainZoras Fountain

Model

What this actor draws, and where each piece lives in the archive. A mod replaces a piece by writing a file at the same path.

Objects loaded

• objects/gameplay_keep shared with 105 other actors
• objects/object_d_hsblock shared with 2 other actors

An edit to a shared object reaches every actor that loads it.
