Arwing
Arwing is a boss actor in Ocarina of Time.
Placement
No known placement issues. This actor's game code has been reviewed, and a placed copy behaves normally.
Type variants (3)
This actor is placed in one of these forms. Pick it from the editor's Type dropdown. The value is what the actor's parameters store.
| Value | Type | |
|---|---|---|
 | 0 | Arwing (intro cutscene)Params 0 is the CUTSCENE Arwing — it seizes the camera for ~100 frames the moment the scene loads. Use params 1 for a plain flying Arwing. |
 | 1 | Arwing |
| No preview yet | 100 | Laser (projectile)Params 100 is the Arwing's laser bolt — it streaks off and vanishes within ~70 frames. |
Parameters
Beyond the type above, the parameters hold these fields. The editor shows each as a labelled control.
Shown: 0x0001, the value a newly placed copy starts with.
- Type
bits 0–15:0Arwing (intro cutscene),1Arwing,100Laser (projectile)The plain Arwing (type 1) is a self-contained flying enemy. Type 0 plays its arrival cutscene, and the Laser is its projectile.
Model
What this actor draws, and where each piece lives in the archive. A mod replaces a piece by writing a file at the same path.
| Display list | overlays/ovl_En_Clear_Tag/gArwingDL |
|---|
Objects loaded
objects/gameplay_keepshared with 105 other actors
An edit to a shared object reaches every actor that loads it.
Also carried in the overlay (31)
The actor's code carries these resources itself, instead of an object.
overlays/ovl_En_Clear_Tag/gArwingBackfireDLoverlays/ovl_En_Clear_Tag/gArwingDebrisEffectDLoverlays/ovl_En_Clear_Tag/gArwingDebrisEffectMaterialDLoverlays/ovl_En_Clear_Tag/gArwingFireEffectDLoverlays/ovl_En_Clear_Tag/gArwingFireEffectMaterialDLoverlays/ovl_En_Clear_Tag/gArwingFlashEffectDLoverlays/ovl_En_Clear_Tag/gArwingFlashEffectGroundDLoverlays/ovl_En_Clear_Tag/gArwingLaserDLoverlays/ovl_En_Clear_Tag/gArwingShadowDLoverlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_003308overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_003388overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_003B88overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_004B88overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_005388overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_005B88overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_006458overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_006708overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_006808overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_006AD0overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_006ED0overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_0071C8overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_008288overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagTex_008540overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagVtx_0028D8overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagVtx_006308overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagVtx_006568overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagVtx_006918overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagVtx_006FE0overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagVtx_0080D8overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagVtx_008398overlays/ovl_En_Clear_Tag/ovl_En_Clear_TagVtx_008850
