Floor/Eye Switch

Floor/Eye Switch is a switch actor in Majora's Mask.

← All actors

Placement

No known placement issues. This actor's game code has been reviewed, and a placed copy behaves normally.

Type variants (6)

This actor is placed in one of these forms. Pick it from the editor's Type dropdown. The value is what the actor's parameters store. Each picture is fitted to its cell, so compare the stated sizes and not the images.

	Value	Type
	0	Floor~12 units tall
	1	Rusty Floor (unused)~12 units tallThe game never gives the rusty floor switch a height, so it lies flat against the floor. The editor draws it at full height.
No preview yet	2	Eye (Arrow)
	3	Crystal~61 units tall
	4	Crystal (Targetable)~61 units tall
	5	Floor (Large)~25 units tall

Parameters

Beyond the type above, the parameters hold these fields. The editor shows each as a labelled control.

• Type bits 0–2: 0 Floor, 1 Rusty Floor (unused), 2 Eye (Arrow), 3 Crystal, 4 Crystal (Targetable), 5 Floor (Large)6 of 8 values used
• Subtype bits 4–6: 0 One-Shot, 1 Toggle, 2 Hold (floor), 3 Inverse Hold (floor), 4 Synced (crystals)5 of 8 values used
• Invisible bit 3: on / off
• Frozen (Red Ice) bit 7: on / off
• Switch Flag bits 8–14: 0–127all 128 values usedOne of the scene's 128 switch flags — actors sharing a number are linked (a setter triggers every consumer on it). Persistence by range: 0–63 saved with the scene, 64–127 temporary (reset when you leave). Pick a number nothing else in this scene uses unless you mean to link them; the panel's link list shows who shares it.

Rotation fields

This actor reads these rotation fields as settings, not as a direction. The editor shows each one as a number field.

Appears in (10)

Ancient Castle of IkanaDeku ShrineInverted Stone Tower TempleMoon Link TrialPirates' Fortress InteriorSakon's HideoutSnowhead TempleStone Tower TempleSwamp Spider HouseWoodfall Temple

Model

What this actor draws, and where each piece lives in the archive. A mod replaces a piece by writing a file at the same path.

Objects loaded

• objects/gameplay_dangeon_keep shared with 9 other actors

An edit to a shared object reaches every actor that loads it.
